    PGP-ADJ

    Manufacturer: Hunter
    As Hunter’s original rotor, the PGP™ delivers unsurpassed reliability, durability, versatility, and value, keeping it the professional’s choice year after year.

    Radius 6.4 to 15.8 m
    Flow 0.10 to 3.22 m³/hr
    Flow 1.7 to 53.7 l/min
    Inlet Size ¾" BSP

    • Pop-up sprinkler rotates silently then dissappears when the job is done
    • Waters evenly and efficiently
    • Has precise pattern control with no wasteful backsplash onto walkways or buildings
    • Through-the-top adjustment with helpful symbol makes it easy to adjust, wet or dry
    • Large dirty water screen puts an end to nozzle clogging
    Manufacturer part number: PGP-ADJ
    *

    Specifications

    Operating Specifications

    • Nozzle choices: 27
    • Radius: 4.9 to 14.0 m
    • Flow: 0.10 to 3.22 m3/hr: 1.7 to 53.7 l/min
    • Recommended pressure range: 1.7 to 4.5 bar; 170 to 450 kPa
    • Operating pressure range: 1.4 to 7.0 bar; 140 to 700 kPa
    • Precipitation rate: 10 mm/hr approximately
    • Nozzle trajectory: standard = 25°, low-angle = 13°
    • Warranty period: 2 years

    Factory-Installed Options

    • Red 5–8 nozzle; Blue 1.5–4.0

    User-Installed Options

    • Drain Check Valve (up to 1 m of elevation) P/N: 142300SP

    Features

    The PGP™ is Hunter’s original product—the item that put the company on the map in 1981. Its exceptional design and impressive performance placed the rotor a cut above back then, and continuous improvements and enhancements have allowed it to remain the number-one-selling rotor in the world ever since. With the ability to deliver even water distribution from engineered nozzles, this sprinkler is unequaled in reliability, durability, versatility, and value. With its endless built-in features and Hunter’s years of experience in gear-drive technology, it’s no wonder the PGP remains the professional’s choice year after year.

    Key Benefits

    Three types of nozzles available for various landscapes: standard red, standard blue, grey low-angle
    Adjustable arc from 40° to 360° to keep water in the appropriate areas
    Factory-installed rubber cover for safety
    Through-the-top arc adjustment for easy installation
    QuickCheck™ Arc Mechanism for fast arc adjustment



    Charts

    PGP Standard Blue Nozzle Performance Data


    PGP Blue Nozzle Performance Data
    View Nozzle
    Nozzle Pressure Radius Flow Precip mm/hr
      bar kPa m m³/hr l/min
    1.5 •
    Blue
    		 1.7 170 8.8 0.27 4.5 7 8
    2.0 200 9.1 0.29 4.8 7 8
    2.5 250 9.4 0.32 5.4 7 8
    3.0 300 9.8 0.35 5.9 7 9
    3.5 350 9.8 0.38 6.4 8 9
    4.0 400 9.8 0.41 6.8 9 10
    4.5 450 9.4 0.43 7.2 10 11
    2.0 •
    Blue
    		 1.7 170 10.1 0.32 5.4 6 7
    2.0 200 10.1 0.35 5.8 7 8
    2.5 250 10.1 0.39 6.5 8 9
    3.0 300 10.4 0.43 7.2 8 9
    3.5 350 10.4 0.47 7.8 9 10
    4.0 400 10.4 0.50 8.3 9 11
    4.5 450 10.4 0.53 8.8 10 11
    2.5 •
    Blue
    		 1.7 170 10.1 0.39 6.6 8 9
    2.0 200 10.4 0.43 7.1 8 9
    2.5 250 10.7 0.48 8.0 8 10
    3.0 300 10.7 0.54 8.9 9 11
    3.5 350 10.7 0.58 9.7 10 12
    4.0 400 10.7 0.62 10.4 11 13
    4.5 450 10.7 0.66 11.1 12 13
    3.0 •
    Blue
    		 1.7 170 10.7 0.50 8.4 9 10
    2.0 200 10.7 0.54 9.1 10 11
    2.5 250 11.0 0.61 10.2 10 12
    3.0 300 11.6 0.68 11.4 10 12
    3.5 350 11.9 0.74 12.3 10 12
    4.0 400 11.9 0.79 13.2 11 13
    4.5 450 11.9 0.84 14.0 12 14
    4.0 •
    Blue
    		 1.7 170 11.3 0.68 11.3 11 12
    2.0 200 11.6 0.73 12.2 11 13
    2.5 250 11.9 0.81 13.6 12 13
    3.0 300 12.2 0.90 15.0 12 14
    3.5 350 12.2 0.97 16.2 13 15
    4.0 400 12.5 1.04 17.3 13 15
    4.5 450 12.5 1.10 18.3 14 16
    5.0 •
    Blue
    		 1.7 170 11.3 0.84 14.0 13 15
    2.0 200 11.6 0.91 15.2 14 16
    2.5 250 11.9 1.02 17.1 15 17
    3.0 300 12.8 1.14 19.0 14 16
    3.5 350 12.8 1.24 20.6 15 17
    4.0 400 12.8 1.32 22.1 16 19
    4.5 450 12.8 1.41 23.4 17 20
    6.0 •
    Blue
    		 1.7 170 11.6 1.01 16.8 15 17
    2.0 200 11.9 1.09 18.2 15 18
    2.5 250 12.2 1.22 20.4 16 19
    3.0 300 13.1 1.36 22.7 16 18
    3.5 350 13.1 1.47 24.5 17 20
    4.0 400 13.4 1.57 26.2 18 20
    4.5 450 13.4 1.67 27.9 19 21
    8.0 •
    Blue
    		 1.7 170 11.3 1.35 22.5 21 25
    2.0 200 11.9 1.46 24.3 21 24
    2.5 250 12.5 1.63 27.2 21 24
    3.0 300 13.4 1.81 30.2 20 23
    3.5 350 13.7 1.95 32.6 21 24
    4.0 400 14.0 2.09 34.8 21 25
    4.5 450 14.0 2.22 36.9 23 26

    Notes:
    All precipitation rates calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.



    PGP Standard Red Nozzle Performance Data


    PGP Red Nozzle Performance Data
    View Nozzle
    Nozzle Pressure Radius Flow Precip mm/hr
      bar kPa m m³/hr l/min
    1  •
    Red
    		 1.7 170 8.2 0.10 1.7 3 3
    2.0 200 8.5 0.11 1.8 3 3
    2.5 250 8.5 0.13 2.1 4 4
    3.0 300 8.8 0.15 2.4 4 4
    3.5 350 8.8 0.16 2.7 4 5
    4.0 400 9.1 0.18 2.9 4 5
    4.5 450 9.1 0.19 3.2 5 5
    2  •
    Red
    		 1.7 170 8.5 0.14 2.4 4 5
    2.0 200 8.8 0.16 2.6 4 5
    2.5 250 8.8 0.17 2.9 4 5
    3.0 300 9.1 0.19 3.2 5 5
    3.5 350 9.1 0.21 3.5 5 6
    4.0 400 9.4 0.22 3.7 5 6
    4.5 450 9.4 0.23 3.9 5 6
    3 •
    Red
    		 1.7 170 8.8 0.18 3.0 5 5
    2.0 200 9.1 0.20 3.3 5 5
    2.5 250 9.1 0.22 3.7 5 6
    3.0 300 9.4 0.25 4.1 6 6
    3.5 350 9.4 0.27 4.5 6 7
    4.0 400 9.8 0.29 4.8 6 7
    4.5 450 9.8 0.31 5.1 6 7
    4 •
    Red
    		 1.7 170 9.4 0.24 4.1 5 6
    2.0 200 9.8 0.27 4.4 6 6
    2.5 250 9.8 0.30 5.0 6 7
    3.0 300 10.1 0.34 5.6 7 8
    3.5 350 10.1 0.37 6.2 7 8
    4.0 400 10.4 0.40 6.6 7 9
    4.5 450 10.4 0.43 7.1 8 9
    5 •
    Red
    		 1.7 170 10.1 0.33 5.5 7 8
    2.0 200 10.4 0.36 5.9 7 8
    2.5 250 10.4 0.39 6.5 7 8
    3.0 300 11.0 0.43 7.2 7 8
    3.5 350 11.6 0.46 7.7 7 8
    4.0 400 11.6 0.49 8.1 7 8
    4.5 450 11.6 0.51 8.6 8 9
    6 •
    Red
    		 1.7 170 10.1 0.42 6.9 8 10
    2.0 200 10.4 0.45 7.5 8 10
    2.5 250 10.7 0.51 8.5 9 10
    3.0 300 11.0 0.57 9.4 9 11
    3.5 350 11.6 0.61 10.2 9 11
    4.0 400 11.6 0.66 10.9 10 11
    4.5 450 11.9 0.70 11.6 10 11
    7 •
    Red
    		 1.7 170 10.1 0.54 9.0 11 12
    2.0 200 10.4 0.58 9.7 11 12
    2.5 250 11.0 0.65 10.8 11 12
    3.0 300 11.6 0.72 12.0 11 12
    3.5 350 12.2 0.78 12.9 10 12
    4.0 400 12.2 0.83 13.8 11 13
    4.5 450 12.2 0.88 14.6 12 14
    8 •
    Red
    		 1.7 170 11.0 0.66 11.0 11 13
    2.0 200 11.3 0.71 11.8 11 13
    2.5 250 11.6 0.79 13.2 12 14
    3.0 300 11.9 0.87 14.5 12 14
    3.5 350 12.5 0.94 15.6 12 14
    4.0 400 12.5 1.00 16.6 13 15
    4.5 450 12.8 1.05 17.6 13 15
    9 •
    Red
    		 1.7 170 11.3 0.73 12.2 11 13
    2.0 200 11.6 0.80 13.4 12 14
    2.5 250 11.6 0.92 15.4 14 16
    3.0 300 12.5 1.05 17.5 13 16
    3.5 350 13.4 1.15 19.2 13 15
    4.0 400 13.4 1.25 20.9 14 16
    4.5 450 13.7 1.35 22.4 14 17
    10 •
    Red
    		 2.0 200 12.2 1.14 19.0 15 18
    2.5 250 12.8 1.29 21.4 16 18
    3.0 300 13.4 1.44 24.0 16 18
    3.5 350 14.0 1.56 26.1 16 18
    4.0 400 14.3 1.68 28.0 16 19
    4.5 450 14.3 1.79 29.9 17 20
    5.0 500 14.6 1.90 31.7 18 21
    11 •
    Red
    		 2.0 200 12.8 1.55 25.9 19 22
    2.5 250 13.7 1.73 28.7 18 21
    3.0 300 14.0 1.90 31.7 19 22
    3.5 350 14.6 2.05 34.1 19 22
    4.0 400 14.9 2.18 36.3 20 23
    4.5 450 15.2 2.30 38.4 20 23
    5.0 500 15.5 2.42 40.4 20 23
    12 •
    Red
    		 2.0 200 12.8 2.03 33.8 25 29
    2.5 250 13.4 2.26 37.7 25 29
    3.0 300 14.3 2.51 41.8 24 28
    3.5 350 14.6 2.70 45.0 25 29
    4.0 400 14.9 2.88 48.1 26 30
    4.5 450 15.2 3.06 50.9 26 30
    5.0 500 15.8 3.22 53.7 26 30

    Notes:
    All precipitation rates calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.



    PGP Grey Low-Angle Nozzle Performance Data

    <

    PGP Grey Low Angle Nozzle
    Performance Data
    View Nozzle
    Nozzle Pressure Radius Flow Precip mm/hr
      bar kPa m m³/hr l/min
    4
    LA •
    Grey
    		 1.7 170 6.4 0.30 4.9 14 17
    2.0 200 6.7 0.32 5.3 14 16
    2.5 250 7.0 0.35 5.9 14 17
    3.0 300 7.3 0.39 6.5 15 17
    3.5 350 7.9 0.42 7.0 13 15
    4.0 400 8.5 0.45 7.5 12 14
    4.5 450 8.5 0.47 7.9 13 15
    5
    LA •
    Grey
    		 1.7 170 7.3 0.33 5.6 12 14
    2.0 200 7.6 0.36 6.0 12 14
    2.5 250 7.9 0.40 6.7 13 15
    3.0 300 8.2 0.45 7.4 13 15
    3.5 350 8.5 0.48 8.0 13 15
    4.0 400 8.8 0.52 8.6 13 15
    4.5 450 9.1 0.55 9.1 13 15
    6
    LA •
    Grey
    		 1.7 170 8.8 0.44 7.3 11 13
    2.0 200 9.1 0.47 7.9 11 13
    2.5 250 9.4 0.53 8.8 12 14
    3.0 300 9.8 0.59 9.8 12 14
    3.5 350 10.1 0.64 10.6 13 15
    4.0 400 10.7 0.68 11.3 12 14
    4.5 450 10.7 0.72 12.0 13 15
    7
    LA •
    Grey
    		 1.7 170 8.5 0.58 9.7 16 18
    2.0 200 8.8 0.62 10.3 16 18
    2.5 250 9.4 0.68 11.4 15 18
    3.0 300 10.1 0.75 12.5 15 17
    3.5 350 10.7 0.80 13.3 14 16
    4.0 400 11.3 0.85 14.1 13 15
    4.5 450 11.3 0.89 14.8 14 16
    8
    LA •
    Grey
    		 1.7 170 9.1 0.71 11.8 17 20
    2.0 200 9.4 0.76 12.7 17 20
    2.5 250 9.8 0.84 14.1 18 20
    3.0 300 10.4 0.93 15.5 17 20
    3.5 350 11.3 1.00 16.6 16 18
    4.0 400 11.6 1.06 17.6 16 18
    4.5 450 11.6 1.12 18.6 17 19
    9
    LA •
    Grey
    		 1.7 170 9.8 0.89 14.9 19 22
    2.0 200 10.1 0.96 16.0 19 22
    2.5 250 10.7 1.07 17.9 19 22
    3.0 300 11.3 1.19 19.8 19 22
    3.5 350 12.2 1.28 21.3 17 20
    4.0 400 12.8 1.37 22.8 17 19
    4.5 450 12.8 1.45 24.1 18 20
    10
    LA •
    Grey
    		 1.7 170 10.1 1.17 19.5 23 27
    2.0 200 10.7 1.26 21.0 22 26
    2.5 250 11.3 1.40 23.4 22 25
    3.0 300 11.6 1.55 25.9 23 27
    3.5 350 12.2 1.67 27.8 22 26
    4.0 400 12.8 1.78 29.7 22 25
    4.5 450 12.8 1.89 31.4 23 27

    Bold = Recommended pressure

    Notes:
    All precipitation rates calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
    *
    *
    *
    *

    Irrigation Unit Conversions

    Convert a given value and unit to different unit type. Conversions are available for flow rate, area, distance, time, volume, pressure, power, precipitation, salinity, and speed.

    Click here to see unit descriptions.


     to
    Area:
     to
    Distance:
     to
    Time:
     to
    Volume:
     to
    Pressure:
     to
    Power:
     to
    Precipitation (Water Application) Rate:
     to
    Salinity:
     to
    Speed:
     to

    Reference: Washington State University
