MegaNet™ 24D

Manufacturer: Netafim

High-performance encapsulated and protected impact sprinkler for field crops and vegetables irrigation

MegaNet™ 24D rotating impact sprinklers, with innovative “fortress” design, deliver very high water distribution uniformity, while preventing performance issues caused by insects, poor water quality and field machine damage. Suits a wide range of applications including crop germination, frost protection and roof dust cleaning.

24-degree water trajectory for vegetables and field crops irrigation with spacing up to 10 x 12 meters
Prevents performance issues caused by insects, poor water quality or field machine damage

Description By Manufacturer
Contact Manufacturer
Unit Conversions
Downloads
Manufacturer Info

Application

Irrigation
Frost mitigation
Orchards cooling
Orchards humidification
Leaves Dust cleaning

Pressure

Medium pressure

Coverage type

Full Coverage: Medium, spacing installation
Full Coverage: Small spacing installation

Crop type

Orchards
Field crops

Trajectory angle

Normal

Why MegaNet™ 24D?

More uniform yields: MegaNet’s symmetric structure creates two equal water jets that optimize the sprinkler’s balance to deliver even better water distribution uniformity.
Long-lasting performance: Innovative encapsulated design with unique pop-up mechanism, that opens only during operation, extends the life of the nozzle and other moving parts by preventing insects and dirt particles from obstructing the sprinkler.
Improves germination: From startup to shut off, MegaNet™ does not groove the soil, preventing seed exposure from the soil. A gentle water jet that distributes relatively small drops near the ground also increases seed germination rates.
Anti-clogging: Integral filter ensures clean water inside the nozzle; this filter can be easily cleaned if needed.
Weather and chemical resistance: Manufactured with UV-resistant materials that can withstand chemicals, fertilizers, and sun exposure.
Versatile installation: Installs on solid sets or on removable field stands.

Specifications

7 different nominal flow rates: 200, 250, 350, 450, 550, 650, 750 l/h. Nominal flow rates at 2.3 bar pressure
Recommended working pressure: 2.0 to 3.0 bar (at the sprinkler head).
Recommended filtration: 400 micron / 40 mesh
Water trajectory angle: 24 degrees
Inlet connection: 1/2" male thread, 20mm ISO inlet (for gluing to PVC riser)
Color-coded locking pins and caps for easy identification
